**Please note this article is part of a larger series that was first released in the June 2021 Monthly Playbook.

Please note this article is part of a larger series that was first released in the April 2021 Monthly Playbook.  If you would like to receive the complete monthly playbook please join below.

If you would like to join the 1,512 others who are receiving high-signal, data-driven analysis to be in front of their peers in the cannabinoid space you can do so below. Each month we spend hours analyzing market research, data trends and private conservations to will keep you in front of the ever-evolving cannabinoid industry.

Cannabis Manufacturing For The 21st Century

Part 6: Overview of Extraction Methodologies & Monitoring

The separation of the wide array of compounds in cannabis sativa L. is becoming more important as regulations on cannabinoid containing products develop and become more stringent. There are a few common solvent methodologies used for extraction in the cannabis industry.

Alcohol extraction uses ethanol and is one of the most common and efficient methods of extracting the cannabinoids. The process can be done in either warm or cold ethanol. In warm or room temperature ethanol, the cannabinoids dissolve quickly leading to a high yield of cannabinoids. For warm ethanol extraction, the initial step is to soak the raw material in Ethanol to pull off the trichomes. In cold ethanol extraction, the first step is to chill the ethanol down to -40˚C before introducing the cold ethanol to the cannabis biomass.

Afterwards, the mixture is collected, filtered and the solvent is evaporated and reclaimed. In warm ethanol extractions, additional purification steps, such as winterization, are necessary. The biggest issue with scaling up this particular process is the ethanol itself. Because of its flammability, it is rated as a Class 1 Division 2 solvent, which limits the amount of Ethanol that can be stored on a particular site.[1] The evaporation of the solvent from the enriched liquid also requires specialized equipment to efficiently evaporate the ethanol to be reused in a closed-loop process.

ABCS Of Cannabinoid Manufacturing

Hydrocarbon extraction generally uses either propane or butane. Similar to the cold alcohol method, the hydrocarbon solvent is cooled down to below it’s boiling point so that it is in liquid form. The initial extraction washes the raw material with the cold hydrocarbon solvent. The hydrocarbons with the products of interest can be separated by flowing the mixture into a separate area and raising the temperature. [2] With low boiling points, the hydrocarbons evaporate well below the point of degradation of some of the more volatile compounds, leaving behind the cannabinoids, terpenes, flavonoids and waxes.

After the separation of the hydrocarbons from the extract, the propane or butane can be recirculated though the biomass creating a closed-looped system. The result is an extract that is relatively free of inactive plant matter such as chlorophyll, fats and lipids. Inline de-waxing can also be accomplished using the same hydrocarbon solvent thereby entirely removing the need for winterization.

Overview of Extraction Methodologies & Monitoring

Despite this advantage, hydrocarbon extraction is losing popularity for several reasons including, but not limited to, regulations for handling propane/butane and stigma attached to a using a hazardous chemical for the extraction. [3] Similar to alcohol extraction, hydrocarbons are flammable, but they are more stringently classified as Class 1 Division 1. Another difficulty is that many places are banning the use of hydrocarbon extraction, making the setup and scale-up of this process unachievable.

In the next issue, we’ll discuss the final extraction method: supercritical CO2. It’s many advantages make it a promising option for those looking to dive into extraction.

laptop-img
Get In touch With Us

Action-Oriented problem solvers ready to go

One Report Once a Month Everything you Need to know

From executive-level strategy to technical know-how, our actionable insights keep you ahead of the pack!

Egyptian Hieroglyphs

**Please note this article is part of a larger series that was first released in the April 2021 Monthly Playbook.  If you would like to receive the complete monthly playbook you can sign up here

Part 5: Cannabis Extraction Methods

The separation of the wide array of compounds in Cannabis sativa is becoming more important as regulations on cannabinoid-containing products become more stringent. There are a few common methodologies used for extraction in the cannabis industry.

Depending on the intended final product, incoming processing can include separation of the flower portions with the highest concentration of cannabinoids and terpenes. Then the extraction of the terpenes and the cannabinoids can begin. Though mechanical separation methods exist, this article will focus on the most common solvent-based
extractions: hydrocarbon, ethanol and super-critical CO2. Solvent extraction methodologies have been around for millennia since the ancient Egyptians made tinctures by soaking herbs in ethanol. Tinctures are created by putting the herbs into a liquid, usually alcohol, to extract the flavors, healing components, etc.

The basic solvent extraction is based on historical methods, although we have made technological advances to help us control the processes over the centuries. Today, common organic solvents include ethanol [1], butane, and propane.[2] Water extraction will not be covered in this article due to its low yields of cannabinoids and terpenes.

Alcohol extraction uses ethanol and is one of the most common and efficient methods of extracting the cannabinoids. The initial step is to soak the raw material in ethanol to remove the trichomes. The polar end (-OH group) of the molecule helps dissolve the hydrophilic compounds, such as chlorophyll. The non-polar end (C2¬H5) helps to
dissolve the hydrophobic compounds such as the plant waxes, oils, cannabinoids, and terpenes.

The process can be done in either warm or cold ethanol. In warm or room temperature ethanol, the cannabinoids dissolve quickly leading to a high yield of cannabinoids. However, the warm ethanol extraction process also dissolves plant lipids including the chlorophyll, which causes a strong bitter taste. By dropping the temperature of the ethanol to less than -30˚C (-22˚F), you decrease the solubility of all the compounds leading to a much slower dissolution of the products into the ethanol. However, it is also below the freezing point of many plant waxes which means that many of the compounds will be solids. The impurities separate from the cannabinoids and can be easily removed.

Hydrocarbon extraction generally uses either propane or butane. Propane and butane are small hydrocarbons, made only of carbon and hydrogen atoms, that are non-polar with low boiling points, (-44˚F and 32˚F, respectively) [3]. The initial extraction washes the raw material with the cold hydrocarbon.

The non-polarity of the molecules helps easily dissolve the cannabinoids, waxes, fats and lipids. Unlike ethanol, there is no polar end to help with the dissolution of certain undesired compounds such as chlorophyll. The terpenes are also easily dissolved in the hydrocarbons, though the flavonoids have limited solubility. The hydrocarbons with the products of interest can be separated by flowing the mixture into a separate area and raising the temperature.[4] With low boiling points, the hydrocarbons evaporate at -44˚F (Propane) and 32˚F (Butane) leaving behind the waxes, fats, lipids, cannabinoids, and terpenes.

After the separation of the hydrocarbons from the extract, the propane or butane can be recirculated though the biomass creating a closed-looped system. The result is an extract that is relatively free of inactive plant matter such as chlorophyll. Hydrocarbon extraction is losing popularity primarily due to regulations for handling propane/butane
and stigma attached to a using a hazardous chemical for the extraction.

The final extraction method uses super-critical CO2. Outside the cannabinoid industry, supercritical extraction methods are used for the production of high-quality hempseed oil, extracting caffeine from coffee, removing pesticides from agriproducts, etc. [5] At standard temperatures and pressures (room temperature and sea-level atmospheric
pressure), all molecules are in their natural state of matter: solid, liquid, gas, or plasma. One can change the state of matter by changing the temperature or the pressure or both. A good example of this would be creating ice cubes in your freezer. Without changing the pressure, you can turn the water into ice by lowering the temperature.

When modulating the temperature and pressure of a system, liquids and gases can hit a critical point where they exhibit characteristics of both liquid and gas. They take up the entire space (more compressible) like gases and have liquid-like densities. This is called a supercritical fluid.[7] Figure 2 shows the phase diagram of Carbon Dioxide (CO2).
Using CO2 has several advantages, it is nonflammable, non-toxic, relatively inert, abundant and inexpensive. [8, 9]

The other main advantage is that at a temperature of 31˚C, you can maintain the supercritical liquid at 74 bar.[6, 7] The various components of cannabis have different solubilities at different temperatures and pressures, thus allowing a clean extraction of the target compounds. However, one study has shown that the concentrations of different products can be extracted at different rates, so the extract should be analyzed. [2, 8, 10]

References:

  1. J. Plotka-Wasylka, M. Rutkowska, K. Owczwarek, M. Tobiszewski and J. Namiensnik, “Extraction with environmentally friendly solvents,” Trends in Analytical Chemistry, vol. 91, pp. 12-25, 2017.
  2. M. May, “The Best Extraction Methods for Marijuan concentrates,” 3 May 2018. [Online]. Available: https://www.analyticalcannabis.com/articles/the-best-cannabis-extraction-methods-for-marijuana-concentrates-300434.
  3. L. G. Wade, Organic Chemistry, 4th Edition, NJ: Prentice hall, 1999.
  4. Marijuana Business Magazine, “Choosing the right cannabis extraction method: Experts weigh in on CO2, hydrocarbon & ethanol,” Marijuana Business Magazine, 2018.
  5. Le Portail Des Fluides Supercritiques, “Applications,” Le Portail Des Fluides Supercritiques, [Online]. Available: http://www.supercriticalfluid.org/Applications.149.0.html.
  6. M. Ollero and D. Touboul, “Lipidomics by Suprictical Fluid Chromotography,” International Journal of Molecular Science, vol. 16, no. 6, 2015.
  7. P. Atkins and J. de Paula, Physical Chemistry, 7th Edition, Oxford Univerisity Press, 2002.
  8. C. L. Ramirez, M. A. Fanovich and M. S. Churio, “Cannabinoids: Extraction, Methods, Analysis, and Physiochemical characterization,” Studies in Natural Products Chemistry, vol. 61, pp. 143-173, 2019.
  9. Airgas, “Safety Data Sheet – Carbon Dioxide,” 12 February 2018. [Online]. Available: https://www.airgas.com/msds/001013.pdf.
  10. A. Beadle, “Advances in Cannabis Extraction Techniques,” 25 June 2019. [Online]. Available:
    https://www.analyticalcannabis.com/articles/advances-in-cannabis-extraction-techniques-311772.
laptop-img
Get In touch With Us

Action-Oriented problem solvers ready to go

One Report Once a Month Everything you Need to know

From executive-level strategy to technical know-how, our actionable insights keep you ahead of the pack!

Chemistry Set

**Please note this article is part of a larger series that was first released in the March 2021 Monthly Playbook.  If you would like to receive the complete monthly playbook you can sign up here

Cannabis Manufacturing for the 21st Century

Part 4: Chemical Difficulties of Real-time Cannabis Process Control

The general product types used to be bud, oil and tinctures. Today, they are further separated into flower, extract, ingestible, tinctures, edibles, sublinguals, and topicals. Flower is still the most-used format although extracts are expected to have the most growth over the next decade. Currently, cannabis is defined by the two most common active ingredients: tetrahydrocannabinol (THC, psychoactive) and cannabidiol (CBD, non-psychoactive). However, there is a plethora of other cannabinoids, the chemical compounds in cannabis, not to mention terpenes as well as flavinoids.

The decarboxylation of CBDA to CBA[4]

Problems can begin to arise since the science of understanding how the diverse array of cannabinoids interact, individually and in concert, with the body is still in its fledgling stages. As research continues to explode in this area, growers and manufacturers are looking for new ways to improve the efficiency of their processes while being able to control the various cannabinoids in the proper concentrations.

The cannabis plant has over 400 chemical molecules and at least 60 of those are cannabinoids, chemicals unique to the plant. [1] [2] [3]. In the plant, cannabinoids are synthesized (made) and stored as cannabinoid acids. When dried, stored, and heated, the acid group (-COOH) comes off and we get the compounds that we are used to thinking about: CBD and THC. (see Figure 1)

While drying and storing allows partial decarboxylation, heating allows full conversion rates. However, the cannabinoids and the terpenes begin to break down over 300˚F, which can be avoided if a lower heat is applied over time. Thus, most conversion happens over time in temperatures just over 200˚F. A list of several known major cannabinoids is shown below. [5]

CANNABINOIDS

  • Tetrahydrocannabinol (THC)
    • ​Delta-8-tetrahydrocannabinol Δ9-THC (or d-8-THC)
    • Delta-9-tetrahydrocannabinol Δ9-THC (or d-9-THC) (most common)
  • Cannabidiol (CBD)
  • Cannabigerol (CBG)
  • Cannabichromene (CBC)
  • Cannibonol (CBN)
  • Cannabinodiol (CBDL)
  • Cannabidivarin (CBDV)
  • Tetrahydrocannabivarin (THCV)
  • Cannabigerivarin (CBGV)
  • Cannabichromevarin (CBCV)

There are also over 100 known naturally occurring non-cannabinoid terpenes, the aromatic components, in cannabis. [1] [2] [3]. Research has shown that cannabinoids and terpenes work together, though the mechanism is still not fully understood. Common terpenes in cannabis include myrcene (mango), limonene (lemon), pinene (pine tree), linalool (lavender), caryophyllene (black pepper and cinnamon), humulene (hops, basil,
clove). Myrcene is the primary terpene in cannabis plants and is responsible for its distinctive aroma. [3]. However, pot-smelling canines are trained to detect β-caryophyllene. For many growers, they cultivate certain strains with known concentrations of various terpenes to create unique odors for their products. Many manufacturers buy custom blends made from botanically derived terpenes. [8]

By extracting and separating the various compounds, especially the CBD and THC, the manufacturers can use analytical methods, such as spectroscopy, to quantitatively measure their compounds and control the actual concentrations of the active compounds in their products, and the manufacturers can precisely control the concentrations of their products including oils, edibles, etc. A difficulty arises in spectroscopy as many of the compounds are similar and thus will give similar spectra. As mentioned previously, statistical models are used to help differentiate the compounds to help enable real-time spectroscopic monitoring of the compounds of interest.

References:

  1. Z. Atakan, “Cannibis, a complex plant: different compounds and different effect on individuals,” Therapeutic
    Advanced in Psycopharmacology, vol. 2, no. 6, pp. 241-254, December 2012.
  2. National Cannibis Prevention and Information Centre, “Cannabinoids,” Alcohol Drug & Abuse Center / University
    of Washington, 2013.
  3. M. Jacobs, “The Difference Between Cannaboids and Terpenes,” February 2020 2019. [Online]. Available:
    https://www.analyticalcannabis.com/articles/the-difference-between-cannabinoids-and-terpenes-311502.
  4. A. Beadle, “CBDA Vs CBD: What are the Differences?,” 18 October 2019. [Online]. Available: https://www.
    analyticalcannabis.com/articles/cbda-vs-cbd-what-are-the-differences-312019#:~:text=Once%20CBDA%20
    has%20been%20formed,lose%20its%20acidic%20carboxyl%20group.
  5. Way of Leaf, “top 10 Cannabinoids: What Are They and What Do They Do,” Way of Leaf, 28 january 2020.
    [Online]. Available: https://wayofleaf.com/education/top-cannabinoids-and-what-they-do.
  6. K. Holland, “CBD vs. THC: What’s the Difference?,” 20 July 2020. [Online]. Available: https://www.healthline.
    com/health/cbd-vs-thc#medical-benefits.
  7. M. Dingman, “Neuroscientfically Challenged,” 7 July 2017. [Online]. Available: https://www.neuroscientificallychallenged.com/.
  8. E. Friedmann, Interviewee, Internal Company Cannabis Discussions. [Interview]. 8 September 2020.
laptop-img
Get In touch With Us

Action-Oriented problem solvers ready to go

One Report Once a Month Everything you Need to know

From executive-level strategy to technical know-how, our actionable insights keep you ahead of the pack!

Cannabis Detective

**Please note this article is part of a larger series that was first released in the February 2021 Monthly Playbook. If you would like to receive the complete monthly playbook you can sign up here

Cannabis Manufacturing for the 21st Century

Part 3: Spectroscopy & Online Process Control for Cannabinoid Manufacturing

Spectroscopy is an analytical tool that started as a qualitative, identification method. However, it soon became apparent that the data can also provide quantitative insights.


Spectroscopy is the measurement of the interaction of electromagnetic (EM) radiation with matter. Visible (Vis) light and heat (infrared/IR light) are the most well-known forms of radiation, but it also includes gamma rays, x-rays, ultraviolet light, microwaves, and radio waves. Each of these types are differentiated by the amount of energy they possess. Ultraviolet light has more energy than visible light, which is one of the reasons it can cause sunburns, skin cancer, and eye damage. For the purposes of spectroscopy, the amount of energy is often denoted in units of wavelength.

A typical seeing person will qualitatively use spectroscopy everyday as they perceive the colors of different objects. Spectroscopic instrumentation allows a user to precisely quantify these observations. For example, branding colors such as Coca-Cola’s or Tiffany & Co.’s have exact colors that are created using specific mixtures of dyes. Online analysis can monitor the creation of the dye during its formulation and blending to ensure that not only is it the right color mixture every single time, but also at every location the dye is manufactured.

SPECTROSCOPY SCHEMATIC

Many spectroscopic instruments utilizes wide-spectrum light that has its broad range of wavelengths physically spread out by an optical component, such as how a prism creates a rainbow of colors. Once the different wavelengths are spaced out, you can place an array of detectors to quantitatively monitor the amount of light at each wavelength. When the light hits a molecule, the two can interact and the molecule can absorb some of the light. Most optical spectroscopies rely on the absorption or transmission of light by a sample and, in general, this absorption of UV, Vis, or IR is non-destructive. [1] The detectors monitor this change (See Figure 1).

With advances in technology, data can often be gathered in milliseconds. Quantitative information is possible because there is a strong proportional connection between the concentration of the chemicals of interest and the amount of light absorbed. The main advantages of spectroscopy is that it is a quick, cost effective, and passive technique that can provide both qualitative and quantitative analyses.

Process tank with an integrated
spectroscopic Solution Process Tank

UV-Vis, near-IR, and mid-IR spectroscopies all rely on the transmission/absorption of light at certain wavelengths. UV-Vis spectroscopy works with the excitement of electrons. The spectra tend to have few features that can cover several hundred nanometers. Near-IR and mid-IR work with the excitation of the vibrations of the atoms within the molecule. The absorption of light in the near- and mid-IR ranges causes numerous features that are usually not as broad as UV-VIS spectral features. The combination of all the features are unique to the molecule. Thus, vibrational spectroscopy can be extraordinarily useful for identifications. [1]


A mix of chemical species can create a matrix with overlapping spectral features. Untangling the intertwined data often requires expertise and numerous hours to create a statistical model that can identify and quantify the product(s) of interest. Software uses the model to quickly covert raw data/spectra into useful information such as the identities of the chemicals in the matrix and their concentrations. Using this data, spectroscopy can be the analytical tool for both qualitative and quantitative checks. For example, a quick check of the amount of moisture in a sample. It can also check a reaction’s progress by monitoring the concentrations of the reactants, intermediates, and/or products.

In the real world, methods exist for incorporating these analytical tools directly into a reactor or pipeline to measure the “sample” directly in the process continuously and in real-time (see Figure 2). This saves both the time and necessity of physically taking samples, both of which can cost a chemical plant millions of dollars. It also allows real-time monitoring of a process where it can be immediately apparent if something unwanted is occurring so that corrective steps can be taken. Beyond the value of instant insight, advanced process sensors also give the benefit of big data aggregation, where additional efficiencies and optimizations can be gained over time.

Outside of the chemical industry, spectroscopy is used for a multitude of applications. An example is the aforementioned measurement of color. Spectroscopy is also widely used in the pharmaceutical industry to measure the various steps of the Active Pharmaceutical Ingredient (API) creation. In the world of forensics, spectroscopy is often used in tandem with other methods to help identify unknown compounds, allowing for a strong case file to be built. In the cannabis industry, spectroscopy has already been implemented to quickly determine the CBD and THC levels [2] as well as moisture % and water activity in dried flower [3].

In the next installment of this series, we will cover the chemical difficulties of cannabis.

References:

  1. D. a. Skoog, F. J. Holler and T. A. Nieman, Principles of Instrumental Analysis, Orlando: Saunders College Publishing, 1998.
  2. Purpl Scientific, “Validation of the Purple Pro for Flower Potency Measurement,” May 2019. [Online]. Available: https://www.purplscientific.com/validation-of-the-purpl-pro-for-flower-potency-measurement/.
  3. Purpl Scientific, “Validation of the Purpl Pro + H2O Pack for Cannabis Water Measurement,” 2020 July. [Online]. Available: https://www.purplscientific.com/validation-of-the-purpl-pro-h2o-pack-for-cannabis-watermeasurement/.
laptop-img
Get In touch With Us

Action-Oriented problem solvers ready to go

One Report Once a Month Everything you Need to know

From executive-level strategy to technical know-how, our actionable insights keep you ahead of the pack!

Spectroscopy Data

**Please note this article is part of a larger series that was first released in the January 2021 Monthly Playbook.

In the world of manufacturing, things move quickly. The manufacturer’s goal is to manufacture their product with the target quality in the proper quantity with as little waste possible. Many manufacturing outlets will do their quality control before a process starts and after the process ends, but what about while something is being created?

Cannabis Manufacturing for the 21st Century

Part 2: Process Control in Cannabis Manufacturing

In the world of manufacturing, things move quickly. A manufacturer’s goal is to manufacture their product with the target quality in the proper quantity with as little waste possible. Process control is actively monitoring your processes so that you can react quickly to control your system if something goes wrong.

Many manufacturers have implemented or are looking to deploy analytical techniques to assess not only the incoming and outgoing goods, but also throughout the processes that transform the raw materials into those final goods. Many basic process tanks monitor simple things, such as temperatures and pressures of all the lines and tank, to help ensure safe working conditions. However, many industries, have moved to putting in more complex technologies so that they can monitor the actual chemical processes that are occurring in their tank.

A first step towards understanding a process is to “thief” samples during the process and measure various characteristics of interest (i.e. cannabinoid concentrations, solvent concentration, water content, etc.) in a lab. This helps to get an idea of the progress and performance of a process; however, there are numerous pitfalls associated with this method. The first pitfall is that someone has to physically retrieve a sample from the process.

Unknown Outliers [1]

This can be a simple and easy task, but it can also require major safety precautions and training for all personnel. On the way to the lab, there is ample opportunity for the sample to be contaminated or to morph as a result of the different environment of the carrying container. Finally, to turnaround test results from the lab may take hours to days to weeks, depending if the lab is on-site, local, or remote. What happens to the process if the tests take an hour, or twenty-four, to give the users a result they can act on? A second sample would have to go through the same process, doubling the time needed to make an effective decision of whether or not to stop the production (Figure 1).

Potentially, a manufacturing site could wait weeks to confirm that their products pass Quality Control and can be shipped to their customers. In a process that can have thousands of gallons of sample every second, it can become problematic if the manufacturing site needs to wait even a few hours to get the results from a thieved sample.

SCHEMATIC OF A PROCESS TANK [1]

Older industries are slow to move to some of the newer technologies for numerous reasons. In the pharmaceutical industry, a change in the process of the manufacturing of drugs requires months, perhaps years, of investigating and validating the change. Even for a large pharmaceutical company, this can be a serious strain on resources. Thus, most pharmaceutical companies will not accept any changes unless they absolutely are
forced into the change. Other reasons are that certain technologies have only caught up to the monitoring speeds that are necessary. In a standard process tank there could be numerous inlets and outlets (see Figure 2). Each of these inlets and outlets can have several points where monitors and controls can be added to the process.

Properly specified sample interfaces allow a spectroscopic sensor to be installed directly into the manufacturing stream to collect data as the process flows past the sensor. These
sensors give a user real-time information on the conditions within their process.

Spectroscopy allows monitoring of the chemical species within the process, and it can be apparent very quickly if an unwanted side-reaction is occurring thereby allowing the user to react and adjust the process. Beyond the value of instant insight, advanced process sensors also give the benefit of big data aggregation, where additional efficiencies and optimization can be gained over time as well. The ultimate goal is to create a control solution that is constantly monitoring the entire system, so that it can proactively, and automatically, change a parameter if something starts to go wrong. This automated
learning would allow for a fully autonomous system that is efficient and safe.

In the next installment of this series, we will begin exploring the benefits of spectroscopy for the inline monitoring of the various stages of manufacturing in the cannabis industry.

References:

  1. S. L. Carrier, Impact of Emerging Tools for Process Control, Bethesda: IFPAC 2018 Conference, 2018.
